Scalable Method for Large-area Integration of 2D Materials

Two-dimensional (2D) materials have a huge potential for providing devices with much smaller size and extended functionalities, Graphene Flagship said.

Author Image

By: Anthony Locicero

Copy editor, New York Post

Two-dimensional (2D) materials have a huge potential for providing devices with much smaller size and extended functionalities with respect to what can be achieved with today’s silicon technologies.    But to exploit this potential we must be able to integrate 2D materials into semiconductor manufacturing lines.    A team of Graphene Flagship researchers in Sweden and Germany now reports a new method to make this work.   The technique, published in Nature Communications by researcher...
